The manual crucible loader is a special manual loader trolley used in fields such as fire assay. It is mainly used to accurately and efficiently place crucibles into equipment like sample melting furnaces. It can hold 25/50 sample melting crucibles at a time, featuring convenient operation, time-saving and efficiency-improving advantages, making it an ideal choice for fire assay laboratories.
It is mainly applied in fields such as fire assay laboratories, ore testing, and metallurgy. Used in conjunction with equipment like sample melting furnaces, it serves to accurately place crucibles containing samples into high-temperature sample melting furnaces for smelting. Additionally, it can be used for tasks such as transporting and storing crucibles.
Advantages
l Loads 25 or 50 crucibles at once, enhancing efficiency.
l Protects operators from direct contact with high temperatures.
l Easy operation with a foot pedal and handle for lifting and placement.
l Features a high-intensity steering wheel with brakes for stability.
l Ensures safe and precise crucible positioning.
l Reduces manual handling and associated risks.
l Customizable loading capacity to meet specific needs.
l Designed for use in fire assay laboratories.
Model | HT-25T | HT-50T |
Max. Loading Capacity | 400kg | 400kg |
Lifting Height | 1500mm | 1500mm |
Fork Size | 900x650x60mm | 900x1200x60mm |
Once Loading QTY | 25 | 30 |
Battery Spec | DC12V,60AH | DC12V,60AH |
Pair With | all crucible | all crucible |
NOTE:It can be used in conjunction with sample melting furnaces 、 cupellation furnaces and crucible flux mixer.
