The fire assay gas-fired type sample melting furnace is widely used in the experiments and production of such fields as electronics, ceramics, metallurgy, glass, and new material development. It is mainly applied to heating and melting samples in fire assay.
Our sample melting furnace is available in a range of sizes, suitable for a range of cupels. Our engineers work closely with our customers to select the right furnace for their needs.
The fire assaygas-fired type sample melting furnace is widely used in the experiments and production of such fields as electronics, ceramics, metallurgy, glass, and new material development. It is mainly applied to heating and melting samples in fire assay.
Advantages of the fire assay sample melting furnace:
1. The independent furnace chamber is convenient for maintenance and replacement, and is suitable for experiments and production in multiple fields;
2. It has a high temperature control precision, and the temperature uniformity and stability inside the furnace chamber are high;
3. The door is opened through pneumatic control, which is convenient to operate and keeps the hot furnace door away from the operator;
4. It is equipped with safety protection measures such as automatic over-temperature alarm output to prevent accidents;
5. High-insulation refractory bricks are used, and the insulation effect is excellent.
Specification Models
Furnace chamber size (mm) | Overall dimension (mm) | Quantity and specification of crucibles (mm) | Temperature(℃) | Heating fuel |
Outer: 500×430×360 Inner: 465×380×310 | 910*950*1750 | 12*50/65g 16*30/40/55g | 1200 | 18KW 3-Phase |
Outer：660*610*360 Inner：600*570*303 | 1300*1100*1850 | 25*50/65g 42*30/40/55g | 1350 | 40KW 3-Phase |
Main technical parameters:
Product Name | Fire assay gas- fired type sample melting furnace |
Furnace Model | HT-12FA-Place and HT-25FA-Place |
Furnace door design | Open up and down |
Heating position | On both sides of the furnace chamber |
Heat source | Gas Fired |
Temperature control accuracy | ±1℃ |
Heating rate | The heating rate can be freely adjusted, and the adjustment range is: the fastest is 20℃ per minute. It is recommended to set the heating rate at 5-10℃ per minute. |
Heating element | Silicon carbide heating elements are adopted. The maximum surface temperature of the elements is 1600°C. |
The opening method of the furnace body | Pneumatic |
Warranty scope and period | The fusion furnace comes with a one-year free warranty, excluding vulnerable parts such as heating elements and thermocouples. |
For more detailed information, please contact us.
